Product Description

Stuart Turner Ch Multistage 4-60 Automatic Flow Switch – 46606

Product Specification

Guarantee: 1 Year
Impeller Type: Stainless steel
Inlet Connection: G 1¼ female
Outlet Connection: G 1 female
Pump Shaft: Stainless steel
Seal Option: EPDM/Carbon/Ceramic

The CHM Automatic Flow Switch range of centrifugal multistage pumps offer a simple solution to pressure boosting where a gravity flow of approx. 1 l/min already exists.

Application
Ideal for the pressurisation of water to outlets in a positive head application, where an instant boosted supply is required from a simple to install package. The range is suitable for commercial or domestic use, pumping hot or cold water.

Features

Fully automatic control – positive head
No on-site setting/commissioning
Built-in ‘no water’ cutout
No pulsing in operation
Easy installation
Reliable
Quiet operation

Technical Specification

The Pump
Body	Brass/stainless steel
Impeller	Stainless steel
Pump shaft	Stainless steel
Seal options	EPDM/carbon/ceramic
Pump connections:
Inlet	G 1¼ female
Outlet	G 1 female
Gross weight (packed)	20.3Kg
The Motor
Power Supply	230/1/50
Enclosure rating	IPX5
Motor	Induction type, permanent capacitor, thermally protected
Nominal watts	1500 Watts
Max. watts consumed	1980 Watts
Amps full load	8.8 Amps
Rating	Continuous (S1)
Operating Conditions
Max. liquid temp.	65°C
Min. liquid temp.	4°C
Suction	Flooded
Max. ambient temp.	50°C
Max. inlet head	10 m
Max. working pressure	10 bar
1 Year Guarantee	United Kingdom only
